Real Time All Wheel Drive

Image:
screenshot of the scene

Author: Ky13harbor9

Group: Default

Filesize: 0.7 MB

Date added: 2012-04-05

Rating: 7.2

Downloads: 4564

Views: 1031

Comments: 7

Ratings: 7

Times favored: 1

Made with: Algodoo v2.0.1 Edu

Tags:

Scene tag
This is a remake of the original back from a while ago. The only thing new here is the 3 circles (red white and blue) composing the Real Time AWD system.

The car would be inable to escape the clutches of the ice on the rear wheel without the RTAWD system (a real system by Honda).

It could just be 4wd all the time, but then it would scrape up the tires on hills.
So, it works by subtracting the front wheel rpm from the rear rpm (or vice versa). If it is greater than 5 or so (rpm) then it will engage the idler (wheel between the two others) to connect the 2 wheels turning the RWD into AWD temporarily.

If you destroy the script for the RTAWD then the car cannot move from the starting place.

Thanks for downloading!

Controls:
Up- Accelerate
Down- Brake
Right- Toggle Parking Brake
Last edited at 2012/04/08 01:07:21 by Ky13harbor9
